PB-Inspired Dynamic Health Model

This repository contains a working Python implementation of a PB-inspired dynamic health model demo for a single longitudinal biomarker or risk score, with an optional 4D “prevention core” that organizes risk into four latent axes and applies a simple intervention rule.

The code here is the same core used in a private case study and is shared only as a generic methodological demo. It does not expose any proprietary 7-axis designs or third-party intellectual property. The naming “PB” is used in a generic, abstract sense and is not tied to any external brand or framework.

Alongside this high-level README, the repository includes a more detailed usage and CLI guide (“PB Dynamic Health Model — Version 5”) which documents the script pb_model_v5.py and its command-line options.

Snapshot

Field

• Computational health modeling
• Longitudinal biomarker dynamics & early-drift detection

Model type

• Single-axis log-normalized state-space model
• Simple two-phase classifier (“Health” / “EarlyDrift”) based on ratio windows
• Optional 4D “PB Prevention Core” with a linear potential and gradient-based nudging

Stage

• Conceptual and numerical prototype
• Implemented as a lightweight Python script (pb_model_v5.py) suitable for small longitudinal series

Main question

Given a small time series of a biomarker or risk score y_n with time points t_n, can we:

• Build a personal baseline and work in a log-normalized space z_n that highlights relative drift?
• Define local ratios and smoothed log-drift that reveal early, subtle departures from baseline (an “early drift” band)?
• Classify time steps into simple phases (“Health” vs “EarlyDrift”) from these ratios in a transparent, non–black-box way?
• Optionally, embed the same series into a 4D latent space [I, M, C, B] with a simple potential V and see how a toy intervention rule would push the system back toward a safer basin?

The emphasis is on clarity and reproducibility rather than sophistication: the code is small, readable, and designed so that non-programmers can run it via the command line with comma-separated inputs.

Model & approach

A. Observed series and log-normalized dynamics

The model starts from a single observed time series:

• Time points t_0, …, t_N (e.g., visits in months or years; strictly increasing).
• Corresponding biomarker or score values y_0, …, y_N, all positive.

The user specifies a subset of indices H ⊂ {0,…,N} that clearly correspond to a healthy baseline (for example, the first 2–3 visits before any known change). From this, the script computes:

• Baseline y_base = (1 / |H|) · Σ_{n∈H} y_n
• Log-normalized series (using an estimated log-baseline c = log(y_base)): z_n = log(y_n) − c
• Step ratios and log-differences: r_n = y_{n+1} / y_n, ℓ_n = z_{n+1} − z_n
• Smoothed log-drift ℓ̃_n over a trailing window W, capturing local trend rather than pointwise noise.
• Early-instability index EI_n: the fraction of points in the trailing window whose ratio r lies inside a user-defined early-drift band [r_low, r_high]. This gives a simple 0–1 measure of how persistently the series is exploring an early-risk regime.

The exit time from the health basin is defined as the first time t_n where |z_n| or z_n² exceeds a user-defined threshold. This is a coarse indicator of when the process leaves its personalized normal range.

B. Simple phase classification (“Health” / “EarlyDrift”)

On top of ratios and smoothed log-drift, the model defines a very simple two-state phase structure S = {Health, EarlyDrift}.

• For each state, a canonical ratio r_center,s and spread σ_r,s are specified, defining how “typical” a given ratio is for that state.
• Given the smoothed ratio proxy r_smooth,n ≈ exp(ℓ̃_n), the script computes a per-time, per-state likelihood: L_{n,s} ∝ exp( −½ · (r_smooth,n − r_center,s)² / σ_{r,s}² ) .
• These are normalized across states to obtain probabilities p_{n,s}, and the phase index is simply Ŝ_n = argmax_{s∈S} p_{n,s}.

The classifier is intentionally local and transparent (no forward–backward HMM yet). The resulting phase index is saved both numerically (in timeseries.csv) and visually (as a step plot over time).

C. Latent log-space dynamics

To demonstrate a minimal dynamic model in log-space, the repository includes a latent process:

z_{n+1} = z_n + μ_{S_n} · Δt_n + η_n,

where μ_{S_n} is a state-dependent drift derived from the canonical ratios for each phase, η_n is Gaussian process noise with variance depending on the current phase, and Δt_n = t_{n+1} − t_n.

This gives a synthetic latent trajectory z_sim,n and corresponding synthetic observed series y_sim,n through a simple log-observation model. These are useful for sanity checks and for understanding how the phase structure interacts with dynamics, but they are not meant to replace more advanced state-space inference.

D. Optional 4D PB Prevention Core

As an optional layer, the code can transform the same 1D series into a simple 4D latent vector: Z^(PB)_n = [I_n, M_n, C_n, B_n]^T, where I, M, C, B are derived from y_n through basic linear / nonlinear transforms chosen purely for demonstration. (In real use, each axis would be defined from different biomarkers or clinical features; here they are placeholders.)

A linear potential is defined: V_n = α_I I_n + α_M M_n + α_C C_n − β_B B_n, and a discrete-time gradient ∇V_n is computed from V(t_n). A toy intervention rule then:

• Identifies time steps where ∇V_n > 0 (risk increasing),
• Applies a bounded negative shift to the I-axis: ΔI_n = −k · ∇V_n (clipped by simple constraints and an optional consistency condition),
• Recomputes V_n after the intervention.

The result (before / after potential, gradients, and applied ΔZ) is stored in pb_core.csv and plotted, giving an interpretable, sandbox view of how a simple rule would “push back” against rising risk in a 4D latent space.

Again, this is generic and illustrative, not tied to any proprietary architecture and not meant for direct clinical use.

Repository contents

Top level

• README.md — this file (high-level overview, safe for public sharing).
• PB Dynamic Health Model — Version 5 — a separate markdown/README file with a detailed CLI & usage guide for pb_model_v5.py, including argument descriptions, outputs, and example commands.

Code

• pb_model_v5.py — single-file implementation of the full pipeline:
  • ObservedSeries — baseline, log-normalization, ratios, smoothed log-drift, early-instability index, exit time.
  • PBPhaseModel — per-step likelihoods from ratio windows, simple phase classifier, and Markov-chain utilities (for simulation).
  • SingleAxisLatentModel — latent log-space dynamics with phase-dependent drift and noise.
  • ObservationModel — log-space observation model to generate synthetic y_sim.
  • PBPreventionCore — optional 4D latent PB axes, potential V, gradient, and intervention rule.
  • CLI entry point main() and the function run_from_cli(args) that orchestrates everything.

Generated outputs

Created under --outdir (default outputs/):

• timeseries.csv
  Columns: t, y, z_obs, r, ell, ell_smooth, EI, phase_idx, z_sim, y_sim
• plot_y.png — observed biomarker vs time
• plot_z.png — log-normalized observed vs simulated latent trajectory
• plot_phase.png — phase index as a step function

If --use_prevention_core is enabled:

• pb_core.csv — potential before/after intervention, gradient, ΔP, and ΔZ components
• plot_V.png — V_before(t) and V_after(t)
• plot_gradV.png — gradient of the potential over time

How to run

For full details and more examples, see the “PB Dynamic Health Model — Version 5” guide in this repo.

1. Install dependencies

pip install numpy matplotlib

2. Run a minimal example

python pb_model_v5.py \
  --times  "0,1,2,3,4,5" \
  --values "1.0,0.97,1.02,1.15,1.30,1.45" \
  --healthy "0,1,2" \
  --outdir "outputs_v5_example"

3. Optional: enable the 4D PB Prevention Core

python pb_model_v5.py \
  --times  "0,1,2,3,4,5" \
  --values "1.0,0.97,1.02,1.15,1.30,1.45" \
  --healthy "0,1,2" \
  --use_prevention_core \
  --k_gain 0.5 \
  --outdir "outputs_v5_pbcore"

Then inspect the CSV files and PNG plots in the chosen output folder.

Relation to broader work

This repository isolates only the concrete PB-based model implemented here:

• A single-axis dynamic health model in log-space
• Simple, transparent phase classification from ratio windows
• An optional 4D prevention core as a sandbox for intervention ideas

It does not include or describe any proprietary 7-axis architectures, nor does it expose third-party or collaborator-specific frameworks. Any future extensions (e.g., more axes, richer state-space inference, or integration with other models) can be layered on top of this code in separate, appropriately licensed projects.

License & usage

This repository is provided as a research and educational case study.

• Use is limited to personal, academic, and non-commercial purposes.
• Do not use this code as-is in clinical, diagnostic, or commercial products.
• Redistribution of modified or unmodified versions is not permitted without explicit written permission from the author.

If you are interested in collaboration, extended access, or using this work under a specific agreement, please contact the author directly.
